Description
Luvocom® 3F PAHT KK 50056 BK FR is a flame retardant High-temperature polyamide. Due to the halogen free ceramic spheres reinforcement you can 3D print flame resistance parts with thicknesses of ≥0.4mm and achieve UL-94 V0. This material is optimised for FFF / FDM 3D printing systems and has enhanced printability with high chemical and mechanical properties. It's a PA6 based material but it exhibits lower water absorption and higher temperature resistance. The filament can be used on conventional FFF / FDM 3D printing systems due to the enhanced printability, improved layer bonding and the unrequired use of a heated chamber. This 3D4Makers PAHT filament features the following properties
- High dimensional stability
- Easy to print, low warping and increased layer adhesion
- Flame retardant UL94 V0 @ 0.4mm (printed test bar)
- UL94 Vertical Burning Test
- EN 45545 (fire behaviour of materials in trains)
- ISO 4589-2 OI (oxygen Index) R22 + R23 - HL1, HL2, HL3
- ISO 5659-2 Ds (smoke density) R22 + R23 - HL3
Material properties
| Description | Value | Test method |
|---|---|---|
| Density | 1,49 g/cm3 | ISO 1183-3 |
| Tensile strength (at 23°C/50% rh) | 55 MPa | ISO 527 |
| Elongation at max. force (at 23°C/50% rh) |
1,2 %
|
ISO 527 |
| Modulus of Elasticity (at 23°C/50% rh) | 6 GPa | ISO 527 |
| Heat Distortion Temp. | 90 °C | ISO 75 |
| Continuous Service Temp. | 120 °C | IEC 60216 |
| Maximum (short term) Use Temp. | 160 °C | / |
| Flammability behaviour | (V-0) |
UL 94 |
| Insulation resistance strip electrode | >10⁹ | DIN IEC 60167 |
| Surface resistance | >10⁹ | DIN IEC 60093 |
| Water absorption | <0,3% | ISO 62 |
Printer recommendations
| Description | Value |
|---|---|
| Printer nozzle temperature | 265 - 290°C |
| Heated bed temperature | 80 - 90°C |
| Print Speed | 40 - 60 mm/s |
| Bed Adhesion |
Magigoo PA on glass or a PEI Sheet |
| Pre drying recommendations | 100°C, 4 hours or 70°C, >5 hours |
| Support materials | HIPS and PVOH materials |
| Extra | We advise to use a adapted nozzle (>0.5mm) for filled filaments |
*Printing profile available in Ultimaker Marketplace
To get the best results while printing we advise you to keep the 3D printer in a room where there is hardly any draft and/or temperature fluctuations. When the 3D printer is not being used it is important to keep filament in a bag and stored in a cool, dry and dark place until it is used again.
Documents
 |
Technical Data Sheet (149 KB) |
 |
Material Safety Data Sheet (250 KB) |
